10L Belt Driven Screw Compressor Small 214KGS 1.1m3 Min
| 원래 장소 | 중국 |
|---|---|
| 브랜드 이름 | OEM |
| 인증 | CE |
| 모델 번호 | CHIC-10A |
| 최소 주문 수량 | 500 |
| 가격 | USD 40-45 |
| 포장 세부 사항 | 사이즈(L×W×H)를 싸는 것 :800mm×600mm×1040mm |
| 배달 시간 | 7일입니다 |
| 공급 능력 | 500PCS/DAY |
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 이름 | 7.5 kw 10 에이치피 CHIC-10A 8 술집 벨트 드리븐은 작은 로타이 스크류 공기 압축기를 사용했습니다 | 항공 투하 | 1.1m3/min |
|---|---|---|---|
| 전기 | 3상 220/60 또는 440/60 (V//Hz) | 압력 | 8bar |
| 소음 수준 | 62±2dB | 힘 | 10HP/7.5KW |
| N.weigh | 214KGS | 색 | 노랑색 |
| 강조하다 | 1.1m3 Min belt driven screw compressor,10L belt driven screw compressor,10L small screw compressor |
||
제품 설명
Motor:
World-renowned high-performance motor, protection class IP54, insulation class F, the bearing adopts heavy-duty bearings,
Screw host:
The high-precision imported twin-screw rotor is adopted, and the volumetric efficiency is as high as 99%. The powerful heart determines the excellent performance of the whole machine
Oil and gas separator
The high-precision imported filter paper rotary filter is used to completely filter out the impurities in the lubricating oil to ensure that the lubricating oil is clean and extend the service life of the compressor
Air valve
Imported air valves from world-renowned brands can automatically adjust air volume from 0-100% to reduce operating costs according to the system air volume requirements
Adopt advanced numerical control processing erquopment for production with high precision and reliability
Low -speed design strict correction of dynamic balance ,computer - optimized design make the operation more stable
Lower noise . longer life more reliable qulity suitable for 24-hour continuous operation
Using advanced surface spraying decoration technology , the product is beautiful and elegant
Technical parameters
| Model | CHIC-10 | ||
| Power | 10HP/7.5KW | ||
| FAD: (M3/MIN) | 1.1 | ||
| Pressure | 8bar | ||
| Cooling | Air-cooling | ||
| Lubricant | 10L | ||
| Noise level | 62±2dB | ||
| Drive method | Belt type | ||
| Discharge temperature | Environment temp+15℃ | ||
| Electricity | Three phase 220/60 or 440/60 (V//Hz) | ||
| Starting method | straight | ||
| Air outlet: Pipe diameter(inch) | R 3/4" | ||
| Oil content of air | <2ppm | ||
| Dimension | 800MM*600MM*1040MM | ||
| Net weight | 214KGS | ||
Packaging & Shipping
Our services
1.We promise to reply your inquiry relational our product within 24hours.
2.OEM&ODM service for your unique idea with absolutely convenient.
3.Experienced foreign trader with professional product knowledge.
4.Value on business credite , promise to protect your sales data, design,patent information.
5. Sample & OEM service is available
6. After-sales service. any question will be settled within 3 days
FAQ
1.Are you a factory or trading company?
A: Our company is a professional manufacturer and trader that is concerned with the design,development
and production
2. What is your delivery time?
A: 15 days for sample order, 30 days for container order. ( Busy season may need more days )
3. How long does delivery take?
A: After receive the deposit:
- Sample order:within 10-15 days;
- 20FT container: 20-25 days;
- 40HQ container: 30-35 days
4. Is OEM acceptable?
A:Yes. In addition to the stable products,OEM & ODM accepted. Please contact us for details.
